« Reply #14 on: April 29, 2011, 06:22:14 PM »


The following morning I continued on the avbay (after another fin-fillet). I epoxied eye-bolts and then attached the threaded rods to one of the plates. These rods keep the avbay as a single unit and also serve as a mount for any electronics you may (or may not) possess.

In my case, I've got a cruddy little USB-altimeter to attach, so instead of making a "slide" out of G10 or balsa sheet as mentioned, I'll probably just hot-glue gun my alt to a carboard tube used to hold a HPR igniter. These tubes also make great launch lugs for MPR rockets:


Logged

They call me Flinty... they call me Johnno... they call me Freddy... always the same...
that's not my name... that's not my name... that's not my name... that's not my name...

EP Rocketry section head
ARA #120
L2 and scheming...
Mr F
ARA Member

Offline Offline

Posts: 919


I am your father!


WWW
« Reply #15 on: April 29, 2011, 06:25:06 PM »

Haha, remember that stink I mentioned. It's day three and I've head all sorts of theories about the source of that horrible stench. I'm sticking with my dead-fish theory. Turns out you just have to ask the right person... or look up rather than down/behind things/under things/in cupboards etc.



who the hell puts a fly trap inside a shed?!?!?!? I'm pretty peeved at the moment (as well as laughing at my own foolishness) because I could've been smelling sweet fresh air the whole build. Hope this doesn't have any impact on the finished product!
Logged

They call me Flinty... they call me Johnno... they call me Freddy... always the same...
that's not my name... that's not my name... that's not my name... that's not my name...

EP Rocketry section head
ARA #120
L2 and scheming...
Mr F
ARA Member

Offline Offline

Posts: 919


I am your father!


WWW
« Reply #16 on: April 29, 2011, 06:27:58 PM »



Finishing off the avbay... I smeared a super-thin layer of epoxy around the end of each coupling tube to reduce wear & tear... After a sand this thing should be a bit more plastic and durable, I hope. I used a cheap, crappy plastic knife as a spatula to get a really thin smear. It worked quite well.
Logged

They call me Flinty... they call me Johnno... they call me Freddy... always the same...
that's not my name... that's not my name... that's not my name... that's not my name...

EP Rocketry section head
ARA #120
L2 and scheming...
Mr F
ARA Member

Offline Offline

Posts: 919


I am your father!


WWW
« Reply #17 on: April 29, 2011, 06:31:26 PM »



Well, after many hours of curing time, the fin can is just about ready! I had considered organising some kind of heat-lamp to speed up the cure but it wasn't necessary really. Rocketry is about patience, sometimes, eh? Last thing to do is attach the recovery harness before reinserting the fin-can.



Knots... knots!!?!?!? This is rocket club, not the scouts! I just learnt a new knot. It actually seems pretty good.



As per destructions... I lathered it in epoxy, presumably to avoid someone suing Binder because their knot turned out shitty. I actually think mine was ok. Anyway, it's going nowhere now!
Logged

They call me Flinty... they call me Johnno... they call me Freddy... always the same...
that's not my name... that's not my name... that's not my name... that's not my name...

EP Rocketry section head
ARA #120
L2 and scheming...
Mr F
ARA Member

Offline Offline

Posts: 919


I am your father!


WWW
« Reply #18 on: April 29, 2011, 06:34:37 PM »

The fin can is ready to be glued into the airframe, BUT... how do I stop the harness getting smeared in epoxy meant for the front centering ring? In the end, I decided to poke all the "rope" through the motor mount. That way, I can add epoxy and insert the fin-can without the harness being in the way at all:



Harness through the tube.



Checking the distribution of epoxy. I added a bit more after looking at this.
Logged

They call me Flinty... they call me Johnno... they call me Freddy... always the same...
that's not my name... that's not my name... that's not my name... that's not my name...

EP Rocketry section head
ARA #120
L2 and scheming...
Mr F
ARA Member

Offline Offline

Posts: 919


I am your father!


WWW
« Reply #19 on: April 29, 2011, 06:37:00 PM »



After sliding the fin-can halfway in, I added some epoxy for the rear centering ring. My wife appeared at this point and took some happy snaps. I included the least embarrasing of them.



Epoxy in place! One advantage of the slow-cure epoxy is you can muck around and take pix with no stress during a build. The 5-min gear goes off like a frog-in-a-sock... no time for happy snaps!
Logged

They call me Flinty... they call me Johnno... they call me Freddy... always the same...
that's not my name... that's not my name... that's not my name... that's not my name...

EP Rocketry section head
ARA #120
L2 and scheming...
Mr F
ARA Member

Offline Offline

Posts: 919


I am your father!


WWW
« Reply #20 on: April 29, 2011, 06:44:46 PM »

At this point I had one of those moments.... the destructions called for a rubber band or equivalent to keep the aft of the body tube tight against the fin-can while the epoxy cured. Do you think, in the entirety of that man-cave, I could find a rubber band? What about the house? In fact, it appeared that all rubber bands had been swallowed by a passing vortex that favoured only rubber-band like materials. In a last ditch effort I looked in the car, knowing full well there were no rubber bands... but what's that on the gear-shift?



Haha, a hair-tie, eh? Don't tell the wife! It worked quite well. The beer is in celebration of the toughest part of the build being done and completed successfully.

Last thing was to check that the front centering ring epoxy was making a fillet. The ring ended up a few mm aft of where I'd thought, so I was a bit worried about it. After holding the body tube at every angle conceivable - inside, outside, under the bathroom light - I took a photo and realised sometimes a camera can look better than you can yourself:






Fillet looks good!
Logged

They call me Flinty... they call me Johnno... they call me Freddy... always the same...
that's not my name... that's not my name... that's not my name... that's not my name...

EP Rocketry section head
ARA #120
L2 and scheming...
Mr F
ARA Member

Offline Offline

Posts: 919


I am your father!


WWW
« Reply #21 on: April 29, 2011, 06:46:32 PM »

That's the build up to this point... sorry for the info-dump! Next jobs are to exterior-fillet the fins and attach launch lug or rail buttons (more on that soon)... till then, i've got a couple more beers in the fridge! I'm drinking one for Goffa who is SA's first official L3! You're my hero Goffa!!!
